Spring Boot and the Holy GraalVM

· 6 min read

With the release of Spring Boot 3.0, we get official support for GraalVM native builds. Does it mean that we can finally free ourselves from the overhead of JVM? How do native builds improve the performance of the app? Where is a tradeoff and is it worth making? In this post, we will try to get some answers to those questions. With some Monty Python references along the way.

Sacred Task
Look well, Developer, for this is your sacred task to seek this Grail.

Spring Native project is now officially part of the Spring Boot 3.0 release. With it, on our side, we can compile Spring Boot projects directly to executables native to the OS, completely omitting Java's VM. Therefore now we can easily run the binary on a system without JRE installed. This is pretty wild! But you might ask why would we ever want to do that. Well... there are a couple of reasons.

JVM was a way to streamline building software that would run on any device, despite OS being installed.

Write once and run anywhere

It's all great, but maybe you don't need this. Maybe you are building a web app and it only needs to run on a Linux OS somewhere in the cloud. In this case JVM is just an unnecessary overhead, that will slow us down.

With GraalVM AOT (ahead-of-time) compilation we can achieve just that. And since it comes freely with Spring Boot 3.0 it has never been a better time to start running your app on directly on the bare metal... or on the cloud's virtualized compute service.

All the tests were made on MacBook Pro with Intel I7-9750H and 16GB of RAM. Benchmark app was running on GraalVM CE 22.3.0. Numbers are an average from 10 consecutive runs.

Clean start

Let's start by looking at the blank app, straight from the Spring Initializer with no additional dependencies, to get the reference point. I will be testing compile time, the final file size will be native or JAR, start-up time and memory allocated by the process.

Compilation time

Compiling an app to the native image takes much longer than building a JAR. In my tests, the average native image took 1m 37s to compile, and building JAR took only 4s - this is almost 25x longer. That's a lot, but we should expect that, AOT is performing some optimisation at the compilation step. In the default HotSpot, JVM's JIT approach those things are postponed until the runtime. AOT compiler is also doing things that JIT will never attempt to do, for instance, AOT will check which resources are never used and can throw away classes from the final build. With JIT we always take everything from the classpath into the final JAR.

File size

File size of the app will be also significantly larger with the native build. In my tests, the blank app took 45.3MB of disk space while the JAR weighed only 14.4MB. The size difference is caused by the fact that the native build is a standalone executable. It does not require any other dependencies like JRE to be started. Meaning we have to pack everything that we might need from JRE inside the binary. JAR will utilize JRE, therefore it can contain only the source code of our app.

Bridge of Death
WHAT... is your quest? Improvements!

Ok. So native image takes longer to compile and weighs more. So far not so great, but let's move to the good parts!

Startup time

Spring Boot apps are infamous for their long startup time. Classpath scanning is one of the things that causes the problem. Since AOT pushes that process to the compile time we are seeing a massive improvement in that regard. During my tests JAR needed 0.774s to boot, while native binary needed only 0.017s. It's 45 times improvement.

Memory usage

Memory usage also seems to be improved. Blank JAR had to allocate 125MB of memory while the native build only need 27MB. That's another place where we can see the benefits of withdrawing JVM.

Summary of all the numbers in a table:

JITAOT
Compile time4s1m 37s
File size14.4MB45.3MB
Startup time0.774s0.017s
Memory usage125MB27MB

1000 Beans

So far we tested the blank app, but what will happen if we would fill up our project with some code. To test this I've made 1000 empty Beans.

It's only a model
Camelot! 1000 Beans! It's only a meaningless model... Shhh

The idea of this test is to see how Beans discovery time would improve the startup time of the AOT build.

JITAOT
Compile time11s1m 32s
File size15.9MB47MB
Startup time1.943s0.043s
Memory usage314MB42MB

Comparing those numbers we can tell that both versions take a hit on the startup time. In both cases, the app needs 2.5x more time to boot. But since the base value of the native binary is much smaller, then the overhead doesn't look that bad. Additionally, we can tell that the native build is much less memory hungry with an increase of lines of code. RAM allocated by native binary is 1.5x times greater over the base value, while JAR needed to allocate 2.5x as much memory.

Sample app

Let's test something closer to the real-life scenario. I will reuse the benchmark app from the previous blog post.

It's a sample app that is just repackaging DTOs and pushing them from left to right. (Something that happens way often in the code that we would like to admit). One of the conclusions from that post was how helpful JIT is, optimising our code on the fly. Can we count on the same help with the native build? Well... no.

JITAOT
No warmup606ms681ms
Warmup373ms642ms
Flesh Wound
No JIT optimisation? It's just a flesh wound.

As you can tell by the numbers if we allow JIT to warm up, the same task will be executed in just 60% of the original time. We don't have the same improvement on the native build, execution time remains similar no matter how much time we spend warming up the code.

If you are thinking about utilising native builds on prod, please benchmark your code carefully. You might be surprised that your app is running slower if you heavily relied on JIT optimisation which is not possible with AOT.

Conclusion

To sum it up with AOT build we are trading longer compile time and larger file size for much faster boot time and lower memory usage. I can think of one place where this tradeoff makes perfect sense - it's the cloud! If you are running your code on the cloud then give it a try. Please keep in mind that to use GraalVM natively with Spring Boot you need to upgrade to version 3.0 or higher. That could be a challenge in itself, especially since Spring Boot 3.0 is using Java 17 as a baseline. Before the upgrade check the full laundry list.
